| Refrigerant | R134A/R513A |
Air cooled screw inverter heat pump, standard efficiency, standard and low sound
Ideal solution for commercial comfort cooling and/or heating applications
Technical Specifications / Documents
| (BIM) Engineering Data Links | Cooling Performance | Cooling Capacity | Heating Performance | Dimensions | Weight | Sound Level** | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Outdoor Unit | Cooling Capacity | Power Input | EER | Heating Capacity | Power Input2 | COP | Height | Width | Length | Operating Weight | Sound Power | Sound Pressure @ 1m |
| kW | kW | kW/kW | kW | kW | kW/kW | mm | mm | mm | kg | dB(A) | dB(A) | |
| EWYD~BZ- SS – Standard Unit | ||||||||||||
| EWYD-BZSS250 | 253 | 91.3 | 2.77 | 271 | 91.6 | 2.96 | 2335 | 2254 | 3547 | 3550 | 101 | 82 |
| EWYD-BZSS270 | 272 | 101 | 2.7 | 298.3 | 100 | 2.97 | 2335 | 2254 | 3547 | 3595 | 101 | 82 |
| EWYD-BZSS290 | 291 | 110 | 2.65 | 325.6 | 108 | 3.02 | 2335 | 2254 | 3547 | 3640 | 101 | 82 |
| EWYD-BZSS320 | 323 | 117 | 2.75 | 334.5 | 118 | 2.82 | 2335 | 2254 | 4428 | 4010 | 101 | 82 |
| EWYD-BZSS340 | 337 | 125 | 2.69 | 350.7 | 127 | 2.77 | 2335 | 2254 | 4428 | 4010 | 101 | 82 |
| EWYD-BZSS370 | 363.4 | 135 | 2.69 | 380.7 | 134 | 2.85 | 2335 | 2254 | 4428 | 4068 | 101 | 82 |
| EWYD-BZSS380 | 380.3 | 144 | 2.64 | 412.1 | 143 | 2.88 | 2335 | 2254 | 4428 | 4138 | 101 | 82 |
| EWYD-BZSS410 | 411.5 | 153 | 2.68 | 444.8 | 157 | 2.84 | 2335 | 2254 | 5329 | 4518 | 102 | 83 |
| EWYD-BZSS440 | 434.2 | 164 | 2.64 | 465.1 | 465.1 | 167 | 2335 | 2254 | 5329 | 4518 | 102 | 83 |
| EWYD-BZSS460 | 454.9 | 164 | 2.78 | 477.4 | 166 | 2.87 | 2280 | 2254 | 6659 | 5255 | 104 | 84 |
| EWYD~BZ- SS B – Standard Unit | ||||||||||||
| EWYD-BZSSB510 | 515 | 183 | 2.81 | 532.9 | 177 | 3 | 2280 | 2254 | 6659 | 5724 | 104 | 84 |
| EWYD-BZSSB530 | 532.6 | 190 | 2.81 | 560.6 | 185 | 3.03 | 2280 | 2254 | 6659 | 5964 | 104 | 84 |
| EWYD-BZSSB570 | 569 | 217 | 2.62 | 618.3 | 208 | 2.97 | 2280 | 2254 | 6659 | 5953 | 104 | 84 |
| EWYD~BZ- SL – Standard Unit | ||||||||||||
| EWYD-BZSL250 | 247.2 | 89.4 | 2.76 | 271 | 91.6 | 2.96 | 2335 | 2254 | 3547 | 3888 | 94 | 76 |
| EWYD-BZSL270 | 265.1 | 99.5 | 2.67 | 298.3 | 100 | 2.97 | 2335 | 2254 | 3547 | 3933 | 94 | 76 |
| EWYD-BZSL290 | 289.9 | 111 | 2.62 | 325.6 | 108 | 3.02 | 2335 | 2254 | 3547 | 3978 | 94 | 76 |
| EWYD-BZSL320 | 314.7 | 115 | 2.75 | 334.5 | 118 | 2.83 | 2335 | 2254 | 4428 | 4343 | 95 | 76 |
| EWYD-BZSL330 | 329.5 | 123 | 2.68 | 350.7 | 127 | 2.77 | 2335 | 2254 | 4428 | 4343 | 95 | 76 |
| EWYD-BZSL360 | 353.5 | 134 | 2.64 | 380.7 | 133 | 2.85 | 2335 | 2254 | 4428 | 4408 | 95 | 76 |
| EWYD-BZSL370 | 370.4 | 144 | 2.58 | 412.1 | 143 | 2.89 | 2335 | 2254 | 4428 | 4478 | 95 | 76 |
| EWYD-BZSL400 | 401.5 | 150 | 2.67 | 444.8 | 157 | 2.84 | 2335 | 2254 | 5329 | 4858 | 95 | 76 |
| EWYD-BZSL430 | 423.3 | 163 | 2.60 | 465.1 | 167 | 2.79 | 2335 | 2254 | 5329 | 4858 | 95 | 76 |
| EWYD-BZSL450 | 446 | 158 | 2.82 | 477.4 | 166 | 2.87 | 2280 | 2254 | 6659 | 5765 | 97 | 77 |
| EWYD~BZ- SL B – Standard Unit | ||||||||||||
| EWYD-BZSLB510 | 502.8 | 178 | 2.82 | 532.9 | 177 | 3 | 2280 | 2254 | 6659 | 6234 | 97 | 77 |
| EWYD-BZSLB530 | 519.2 | 186 | 2.8 | 560.6 | 185 | 3.03 | 2280 | 2254 | 6659 | 6474 | 97 | 77 |
| EWYD-BZSLB570 | 569.0 | 217 | 2.62 | 618.3 | 208 | 2.97 | 2280 | 2254 | 6659 | 6463 | 97 | 77 |
Key Features & Technology
It's the unique features of Daikin products that makes us the world leader.
Inverter
Inverter compressors continuously adjust compressor speed to actual demand. Fewer power-consuming starts and stops result in decreased energy consumption (up to 30%) and more stable temperatures.
Screw Compressor
Single screw compressors have rotors with male and female gears and are designed for high capacities and performances
DX Shell and Tube Evaporator
DX shell and tube evaporator – one pass refrigerant side to minimize pressure drops
Low starting current
Low starting current
